lm7912-TO-220

NEGATIVE VOLTAGE REGULATOR

• TO-220 Package
• Up to 1.5A output current (Some manufacturers also make in 1A output current)
• Short circuit protection circuitry
• Overheat shutdown circuitry
• Low price
• Reliable for commercial use
• Stable -12V output
• Maximum input voltage is 35V DC
• Low quiescent current


  LM7912 Description

  LM7912 is negative voltage regulator IC of LM79XX series provides accurate and stable -09V output, there are also other negative voltage regulators in this series which are LM7905, LM7906, LM7908, LM7909, LM7910, LM7912, LM7915, LM7918 and LM7924. All the ICs in this series are available in TO-220 package and have 3 output pins which are Input, Output and Ground. The IC also have many features like thermal overload protection, safe area protection, short circuit protection etc. all these features makes this IC robust and reliable for commercial equipment and also for experimental projects of students and tinkerers.

  Moreover, the IC requires only one component at the output which is a capacitor that stabilizes the output voltage. The input capacitor is only necessary if the IC is more than 3 inches far from the input supply filter capacitor. If the input and output capacitors values are more than 100uf then two protection diodes should be used to protect the IC from capacitors output spikes to protect the IC’s internal circuitry from damaging.

Datasheet :l7912cv
