The SG3524 incorporates on a single monolithic chip all the function required for the construction of regulating power supplies inverters or switching regulators. They can also be used as the control element for high power-output applications. The SG3524 family was designed for switching regulators of either polarity, transformer-coupled dc-to-dc converters, transformerless voltage doublers and polarity converter applications employing fixed-frequency, pulse-width modulation techniques. The dual alternating outputs allows either single-ended or push-pull applications.Each device includes an on-chip reference, error amplifier, programmable oscillator, pulse-steering flip flop, two uncommitted output transistors, a high-gain comparator, and current-limiting and shut-down circuitry.

SG3524 Specifications & Features

• Supply Voltage: 8V to 40V
• Output Voltage: 4.6 V to 5.4 V
• Output Current: 50 mA
• Number of Outputs: 2 Output
• Topology: Boost, Buck, Fly-back, Forward, Push-Pull
• Switching Frequency: 722 kHz
• Duty Cycle – Max: 45 %
• Fall Time: 100 ns
• Rise Time: 200 ns

datasheet :SG3524
